Multilink 018-039-20 Camera Control Interface
Multilink 018-039-20 Camera Control Interface
Ul Camera Control Interface 018-039-20 Provides Integrated Functionality In Powering And Controlling A Video Camera At Remote Locations. Controlled Using Joystick Or Remotely Using R2- 232/485.
General Specifications Frequency 60Hz �3Hz Led Display Four Leds On Front Panel Indicate Operational Status Amber: System On Red: Camera On (2) Green: Local On (Joystick Or Rs232) Input Power 100 Va; 115 Watts, Max Mounting Dimensions 18.25-Inch Mounting Centers 19-Inch Rack Mountable Eia/Tia Spacing Input Protection 1.5 Amp, 250 Volt, Slow Blow, Glass Type Fuse Output Protection 4 A, 250 V Type Agc-2 Fuse (1/4" X 1-1/4" Glass Tube Fuse)
General Specifications Efficiency Better Than 90% Over Line Voltage Range, At Full Load Output Specifications Output Current 4 A
Physical Specifications Width 17.0" Height 3.5" Depth 8.5" Weight 13 Lbs. Ac Input Specifications Ac Input Voltage 120 Vac, Nominal; Single-Phase Only Ac Input Current 1 A @ 120 Vac Line Voltage Tolerance 105 To 125 Vac Ac Output Specifications Output Voltage 24 Vac Camera Power Output Power 96 Va Environmental Specifications Operating Temperature -40�C To +60�C (-40�F To +140�F) @ 5% To 95% Relative Humidity, Non-Condensing
