Features
- One through-hole for easier installation of threaded rod
- Versa-Mount Technology: Innovative attachment design provides multiple structural and installation methods for wall, ceiling, and threaded rod mounting applications
- Improved design allows for optimized inventory, reducing job site scheduling risks associated with multiple SKUs
- Provides optimal support for high-performance data cable—including category cable, Power over Ethernet (PoE), and fiber optic
- Complies with EN 50174-2
- Meets ISO®/IEC 14763-2, ANSI®/TIA 568 and ANSI®/TIA 569
| Capacity(70% Fill) | ||||||||
| Cable | Number of Twisted Pairs | AWG | Cable Diameter | CAT16HP | CAT21HP | CAT32HP | CAT48HP | CAT64HP |
| UTP | 4 | 24 | 0.197 in | 20 | 30 | 70 | 160 | 280 |
| FTP | 4 | 24 | 0.236 in | 15 | 20 | 50 | 110 | 190 |
| SFTP | 4 | 24 | 0.236 in | 15 | 20 | 50 | 110 | 190 |
| SFTP | 4 | 23 | 0.276 in | 10 | 15 | 40 | 85 | 140 |
| F/STP | 4 | 23 | 0.335 in | 7 | 10 | 25 | 60 | 100 |
| SFTP | 4 | 23 | 0.335 in | 7 | 10 | 25 | 60 | 100 |
| SFTP | 3x4 | 24 | 0.551 in | 2 | 4 | 9 | 20 | 35 |
| UTP | 25 | 24 | 0.512 in | 3 | 5 | 11 | 25 | 40 |
Non-continuous supports may not exceed spacing of 5' (1.5 m) per TIA 569-C.9.7 and EN 50174-2.
Cable capacity is calculated based on a 70% fill rate.
